Enhancing Transport Safety of Magnet Cranes Using Thermometer

In steel mills, iron slabs after manufactured are transported by magnet cranes (lifting magnet). If the temperature of the iron slab is too high, the magnetic force of the crane gets weakened, so the temperature of the iron slab must be reduced to an appropriate temperature.

Therefore, it is necessary to go near to the crane to measure the surface temperature of the iron slab before transportation, but this is a time consuming and labor intensive process.

HORIBA provides safer and effective solution to magnet crane transportation with high sensitive infrared thermometers, IT-545 and IT-480.

Do you have such a problem with temperature control of magnetic cranes?

Need to maintain a safe distance from the measurement object for safety
Time consuming due to manual checks
Repeatedly checking the exact measurement point from a far distance is difficult
Temperature checks has to be done by visiting harsh environment.

HORIBA's Solution

“ Thermometer for Magnet Cranes” is the solution!

Can be measured from a far distance ( approx. 10 m)
Highly accurate and stable real time measurement
Continuous operation even in harsh environment

Example of Installation

Features

The thermometer for magnet cranes is a system consisting of (1) a thermometer IT 480F, ( 2 ) a measuring unit, and ( 3 ) a display unit.

(1) Thermometer IT-480F

Measure up to 10 meters away.
Minimizing the influence of ambient temperature to achieve highly accurate and stable real time measurement. (Patent No. 565809)

(2) Measurement Unit

Easy setup for measurement and positioning of the measurement target with a sighting laser.
Purges the inside of the unit with instrumentation air continuous operation for a long time even in harsh environment.
