Fluorolog-QM

Modular Research Fluorometer for Lifetime and Steady State Measurements

The HORIBA Fluorolog-QM™ series of modular research grade spectrofluorometers is the fourth generation of the world famous HORIBA Fluorolog, with the first Fluorolog introduced by Spex Industries in 1975.

The Fluorolog-QM represents the culmination of decades of HORIBA’s industry-leading experience in development and manufacture of the highest level of spectrofluorometer performance and versatility. The Fluorolog-QM, with its exquisite, optically perfect, all reflective optics, combined with a multitude of light source and detector options, and sample handling accessories, provides the highest sensitivity and greatest versatility of any spectrofluorometer.

The Fluorolog-QM can be enhanced to suit a broad array of luminescence experiments, with the industry’s most extensive list of optional accessories to expand capabilities and performance, to meet all of the most demanding research lab’s experimental needs. And when you purchase a Fluorolog-QM all of these enhancements and accessories can be added to your system at any later time as your needs change, or funds become available.

With thousands operating in universities and research labs around the world, and tens of thousands of publications, Fluorolog has proved itself to be the best choice for the most demanding steady state, time-resolved, TCSPC, PLQY and NIR research.

Segment: Scientific

Division: Fluorescence Spectroscopy

Manufacturing Company: HORIBA Scientific

Featured Videos

4th generation from the Fluorolog series spectrofluorometers

Spectroscopy in :60 - Up Conversion

Spectroscopy in :60 - SSTD

Unique Fluorolog-QM™ Benefits

All reflective optics for perfect performance at all wavelengths
Highest guaranteed sensitivity (more than double that of the Fluorolog-3)
Excellent stray light rejection with extra-large, coma corrected, 350 mm single, or 700 mm double additive monochromators
New software for all steady state and lifetimes experiments, with many new features
Extended wavelength range from Deep UV to NIR
Up to four light source types, and six detectors, can all be connected at once, under computer control, for ultimate lab versatility
World class, plug and play, TCSPC lifetime enhancements, at speeds up to 100 MHz
NIR steady state and phosphorescence lifetime detection to 5,500 nm
Deep UV excitation down to 180 nm

For more features download the Fluorolog-QM brochure.

Optional Pulsed Laser and LED Light Sources

The following specifications are for the standard Fluorolog-QM-75-22 system.
Options and upgrades may be available upon request.

Signal-to-Noise Ratio	(>35,000:1 FSD)
Data Acquisition Rate	1,000,000 points/sec. to 1 point/1000 sec.
Inputs	4 photon counting (TTL); 4 analog (+/- 10 volts); 1 analog reference channel (+/- 10 volts); 2 TTL
Outputs	2 analog (+/- 10 volts); 2 TTL
Emission Range with standard PMT	185 nm to 900 nm (optional to 5,500 nm)
Light Source	High efficiency “ECO” friendly continuous 75 W Xenon arc lamp (Optional 450 W Xenon)
Excitation and Emission Monochromators	700 mm, triple grating, coma-aberration corrected, asymmetrical, excitation or emission optimized, Czerny-Turner design with computer controlled slits at entrance, intermediate plane and exit.
Slits	Computer controlled, continuously adjustable
Excitation Grating	1200 line/mm 300 nm blaze, (Up to two optional gratings can be ordered)
Emission Grating	1200 line/mm 400 nm blaze, (Up to two optional gratings can be ordered)
Wavelength Accuracy	+/- 0.3 nm
Minimum Step Size	0.01 nm (grating dependent)
Standard Detection	Multimode, -20 degrees Celsius cooled, 1600 Volt PMT housing; Multimode: Photon Counting, 3 analog (fast, medium, slow response), direct and Single-Shot Transient Digitizer (SSTD) mode, and Time-Correlated Single Photon Counting (TCSPC), R928P PMT standard (other PMT's available)
R928P PMT Dark Count:	10 counts per second or less
R928P PMT Maximum Linear Count Rate:	10,000,000 counts per second
System Control	Computer interface with FelixFL spectroscopy software
Lifetime Range	5 ps to seconds with appropriate time-resolved accessories

HORIBA Scientific has a policy of continuous product development, and reserves the right to amend part numbers,
descriptions and specifications without prior notice.

Selection Guide for Solid State NIR Detectors on the Fluorolog-QM

This technical note serves as a guideline to selecting the best solid state detector with the Fluorolog-QM modular research spectrofluorometer for a given series of photoluminescence experiments.
