FTX-ONE-CS/RS

FTIR Exhaust Gas Analyzer Direct Measurement Type

FTX-ONE is a fast response and compact size FTIR analyzer for the simultaneous measurement of multiple components of engine exhaust gases.

The FTX-ONE offers a 5Hz sampling rate and simultaneously measure the concentrations of multiple components including NH₃, CH₄, and CO₂, from (engine) direct exhaust gas using the Fourier Transform Infrared (FTIR) method in combination with multivariate analysis algorithm.

Segment: Automotive

Division: Emission Measurement Systems

Manufacturing Company: HORIBA, Ltd.

Fast Response and Compact Size FTIR Analyzer for the Simultaneous Measurement of Multiple Components of Engine Exhaust Gas

FTX-ONE-CS

Offers a 5Hz sampling rate and simultaneously measure the concentrations of multiple components including NH_3, CH₄ and CO₂, from (engine) direct exhaust gas using the Fourier Transform Infrared (FTIR) method in combination with multivariate analysis algorithm.

FTX-ONE-RS

FTX-ONE-RS is the rack type measurement system combined detector of FTX-ONE-CS and THC / O₂ detector. The remote EGR measurement unit is available as an option.

Applications

Latest Regulations
・Engine and Vehicle Development for Euro 7*: For R & D applications in anticipation of the EU's next LDV regulation (measurement of NH₃, N₂O, etc.)
・Measurement for EU Latest Regulation: Complaint to NH₃ concentration regulation certification under EU HDV regulation (Euro VI) and NRMM regulation (Stage V).

* Please contact our sales staff for details

Evaluation of Catalyst and Fuel
Evaluation of aftertreatment systems such as urea SCR, gasoline three-way catalyst, and bioethanol fuel.

Features

Fast Response
The world's smallest high performance optical cell* realizes a fast response time of about 1.5 seconds** even for NH3, which is difficult to measure.

Low Sampling Flow Rate
Achieves low sampling flow rate sampling with the world's smallest high-performance optical cell* and enables measurement without affecting engine combustion or catalyst performance.

* According to our research in May 2018 ** Response speed T_10-90 is about 1.5 sec on the calibration line

Compact Design (FTX-ONE-CS)
Approx. 1/2 the installation area and weight.* Improved freedom of layout and maintainability in the lab.

* At the size of the footprint

Fuel Consumption and A/F (FTX-ONE-RS)
Simultaneous measurement of THC and O₂ enables correlation evaluation of fuel consumption, A/F, and emission trends of each component with a single unit.

Outline

	FTX-ONE-CS	FTX-ONE-RS
Measurement target	Exhaust gas from internal combustion engine (Direct measurement)
Target components^*1	Max. 28 components	Max. 28 components including THC, O₂
Target components sets*^₂	Gasoline / Diesel set CNG set Ethanol set	Gasoline / Diesel set CNG set Ethanol set
Principle	Fourier Transform Infrared (FTIR)	Fourier Transform Infrared (FTIR) THC: Heated Flame Ionization Detection O₂: Paramagnetic Detection
Sampling line temperature	113°C ± 6 °C or 191 °C ± 6 °C	113°C ± 6 °C or 191 °C ± 6 °C
Sampling gas flow rate	Approx. 3.5 L/min	Total Approx. 8 L/min
Operating environment	Ambient temperature 5 - 40 °C Ambient humidity: less than 80 % relative humidity (non condensing)	Ambient temperature 5 - 35 °C Ambient humidity: less than 80 % relative humidity (non condensing)
Power requirements^*3	Approx. 2.8 kVA as MAX., Approx. 2.2 kVA at stable state	Approx. 4.5 kVA as MAX., Approx. 3.5 kVA at stable state
Dimensions^*4	438(W) × 661(D) × 950(H) mm	655(W) × 850(D) × 1970(H) mm
Mass^*4	Approx.150 kg	Approx. 430 kg

*1：Select when ordering from the “Measuring Components and Ranges” table
*2：Standard combination of components and ranges, specified at time of order
*3：With heated filter, heated hose (CS: 15 m, RS: 12 m) and THC/O₂ analyzer (only RS)
*4：Excluding protrusions

Measuring Components and Ranges^*1

Components	Gasoline / Diesel
CO	0-200ppm 0-1000ppm 0-5000ppm 0-2 vol% 0-10 vol%
CO₂	0-1 vol% 0-5 vol% 0-20 vol%
NO	0-200ppm 0-1000ppm 0-5000ppm
NO₂	0-200ppm
N₂O	0-200ppm
H₂O	0-24 vol%
NH₃	0-100ppm 0-1000ppm
SO₂	0-200ppm
HCHO^*2	0-500ppm
HCOOH	0-100ppm
CH₄	0-500ppm
C₂H₄	0-500ppm
C₂H₆	0-200ppm
C₃H₆	0-200ppm
1,3-C₄H₆	0-200ppm
iso-C₄H₈	0-200ppm
C₆H₆	0-500ppm
C₇H₈	0-500ppm
NOx / HC sum	Sum
THC (RS only)	0-10 ppmC - 60000 ppmC
O₂ (RS only)	0-1 vol% - 25 vol%

*1: The following are optional: Add other components (methanol, ethanol, acetaldehyde, MTBE, DME, acetone and acetic acid), to interchange other components and to change ranges. Please contact HORIBA for optional arrangements.
*2: Reference component
